Single End Resistance Heating Rod For Curing Oven
Single End Resistance Heating Rod For Curing Oven
Single end resistance heating rod cartridge heater are made of crimped-on or swaged-in construction that consists in a resistance wire wound around a high-quality MgO core that is centered in a stainless steel casing.
Product Detail
| Sheath Material | SUS304.321.316,Incoloy800.840,Titanium |
| Resistance Wire | Ni-Cr or FeCr |
| Insulation Material | High-purity Mgo |
| Watt Density | 5-30W/cm2 (advisable) |
| Lead wire type | Crimped or Swaged leads |
| Working Temperature | Max 800C |
| Lead and type | 10″ Fiberglass Standard (silicone/PTFE/pure nickel glass fiber) |
| Lead Protection | Stainless Steel Hose/Stainless Steel Braid/Galvanized Conduit |
| Internal thermocouple | Type J or K available |
| Thermocouple Location | Disc End, Sheath, Center of Heater |
| Product Keywords | Single end resistance heating rod cartridge heater |
