PDLC-FCAPC Outdoor Single mode Fiber Optic Patch Cord
Product name : PDLC-FCAPC Outdoor Single mode Fiber Optic Patch Cord
Products Category: > Fiber Patch Cord
PDLC-FCAPC Outdoor Single mode Fiber Optic Patch Cord
Duplex GYXTW PDLC Outdoor Single mode Fiber Optic Patch Cord
Optical Patch cord so called fiber cable assembly is connector terminated both ends and ready for installation. TTI Fiber offer full-range of optic fiber Patchcords at FC, SC, ST, LC, MU, MTRJ, MPO… – PC, UPC or APC connectivity.
Features:
Low insertion loss and high return loss
Support 10 Gigabit data transmitting rates
MM cables type
Polishing: PC, UPC and APC
Meets IEC standard
Applications:
Telecommunication networks
Fiber optic communication networks
CATV, LAN, MAN, WAN, Test &Measurement
Optical access network
Specification:
| Mode | Single mode | Multimode | |
| Polish | UPC | APC | PC |
| Insertion Loss | ≤0.2dB | ≤0.3dB | ≤0.2dB |
| Return Loss | ≥55dB | ≥65dB | ≥35dB |
| Interchangeability | ≤0.2dB | ||
| Salt Spray | ≤0.1dB | ||
| Repeatability | ≤0.1dB (1000 times) | ||
| Vibration | ≤0.2dB (550Hz 1.5mm) | ||
| Temperature | ≤0.2dB (-40+85 sustain 100 hours) | ||
| Humidity | ≤0.2dB (+25+65 93 R.H.100 hours) | ||
| Apex Offset | 0μm ~ 50μm | ||
| Radius of Curvature | 7mm ~ 25mm | ||
| Standards-Compliant | ROHS,IEC and GR-326 | ||
