HK-30Y CE Fiber Polishing Machine With Two Japan Motors &…
Product name : HK-30Y CE Fiber Polishing Machine With Two Japan Motors &…
Products Category: > Fiber Polishing Machine
HK-30Y CE Fiber Polishing Machine With Two Japan Motors & Gear Working
HK-30Y fiber polishing machine all components from Japan,included switch,motors,tray,spring,shell etc. So the quality is very well.
HK-30Y with following features:
High-yield Operation
It is capable of polishing up many ferrules at once in a short time. (The number of
ferrules varies slightly depending on the types of connectors.)
Easy Operation
Both maintenance and operation are remarkably easy and require no special skills.
Wide Range of Application
Applicable to FC, SC,LC,ST,E2000,MPO,MTP,MTRJ and various other connector types in high-physical contact,
Pressure way | 4 coil spring | Insert Loss | 0.3 dB (SM) 0.2 dB (MM) |
Polishing capacity(max) | SC, FC, ST: 20, 48 units LC: 24, 48units | Return Loss | 50 dB (PC) 60 dB (APC) |
Polishing connector type | FC, SC, ST, LC, MU, MTP, MPO, MTRJ and so on | Radius | 10~25mm |
Motor speed | 90rpm rotation, 2rpm revolution | Offset | 50 μ M |
Dimension | 230*230*255mm | Under cut | 50nm |
Film size | 5′ ‘ | Repeatability | 0.1dB |
Weight | 24KG | Interchangeability | 0.2 dB |
Input voltage | 100-120VAC, 50/60Hz or 220-240VAC, 50/60Hz | Working Situation Temperature | -10— +40º C |
Polishing cycle | 2.83mins | Heavy punch | 500g or 250g |
Polishing chassis diameter | 130mm | ||
Polishing time setting | 0-3min | ||
Counterweight pressure | 2.1~3.6kgf/cm | ||
Time Range | 0-300S | ||
Polishing Time | 2 min. (quick assembly type) | ||
3-4 min. (standard connectors) | |||
Pressure Range | 0~5kg | ||
Precession Speed | 1.5rpm |
