CPRI cable, OD Fiber OD-LC OD Dual, MM, LC dual…
Product name : CPRI cable, OD Fiber OD-LC OD Dual, MM, LC dual…
Products Category: > Waterproof Fiber Series Products
CPRI cable, OD Fiber OD-LC OD Dual, MM, LC dual Fiber Patch Cord
IHfiber fiber optic cable assembly is used in FTTA applications,All fiber cables listed in the below tables can be connected to both RF Modules and Remote Radio Heads. System Module compatibility depends on whether the module is an outdoor or indoor variant. Halogen-free.
At one side or both sides, LC Duplex connector adopt with angle tube. it can be bended to 90 degree or 45 degree or straight. Or adopt with flexible tube, it can be routed either left,right or straight.
Assembly
Connector A LCD/UPC, multi-mode(MM)
Connector B LCD/UPC, multi-mode(MM)
Cable 7.0mm 2F LSZH, Black,OM2,50/125um optical fiber according to ITU-T G651
Cable Attenuation <=3.5dB/km @ 850nm / <=1.5dB/km @ 1300nm
Parameter
Insertion loss Max.0.5dB+3.5dB/km*L @850nm
Max.0.5dB+1.5dB/km*L @1300nm
according to IEC 61300-3-4 Method C
Return loss Min.30 dB according to IEC 61300-3-6 method
| Specifications: | |||||
| InsertionLoss(IL) (IEC 61300-3-4) | MM | SM Super PC | SM Ultra PC | SM Angle PC | SM Angle PC Premiun |
| 0.15dB type | 0.15dB type | 0.15dB type | 0.15dB type | 0.1dB max | |
| ReturnLoss(RL) (IEC 61300-3-4) | >30dB | >45dB | >50dB | >60dB* | |
| Operating temperature | ﹣40℃ to ﹢50℃ | ||||
| Durability | min 1000 cycles | ||||
| Assemblity | glue and polish | ||||
| Connection | physical contact | ||||
| Lock mechanism | coupling nut and snap-on | ||||
| Standards | Telcordla GR-3120 | ||||
| Ferrule material | full ceramic zirconia | ||||
