Adjustable fiber polishing machine HK-12D

Adjustable fiber polishing machine HK-12D

1.This machine is utomatic central pressurized, adjustable fiber polishing machine developed with the use of industrial grade industry-specific microcomputer, and this adjustable fiber polishing machine development and into set motor speed, time and count in an organic whole, the adjustable fiber polishing machine improve the stability of the machine. Our the new adjustable fiber polishing machine dopting advanced technology.

2. HK-12D product introduction:
The adjustable fiber polishing machine designed for polishing ceramic, quartz, glass, metal and plastic etc. And this adjustable fiber polishing machine can manufacture various standard optical fiber connectors: FC/UPC, SC/UPC, ST/UPC, LC/UPC, MU/UPC, FC/APC, SC/APC, MT – RJ, E2000 etc various types of optical fiber connectors should may at any time storage, edit pressure and time parameters.

This fiber polisher is easy to change jig and polishing films, simple to disassemble and increase pressure.

The machine also can grind to other similar products
1. The power switch: Control the adjustable fiber polishing machine the opening/closing.
2. Start switch: Control the machine operation.
3. Insurance (FUSE): Insurance specifications for: 250V / 0.5 A.
4. Governor: To adjust motor speed, in order to satisfy the needs of different materials for grinding.
5. Open and close button: Press “RUN” button, the adjustable fiber polishing machine running, press the”STOP” button, equipment stop working.
6. Timer: Setting and display the polishing time.
7. Counter: Record grinding number, if want to recount, can press the reset button.
8. Heavy hammer: Adjust heavy hammer position, adjustable grinding pressure, a total of three different gear is available.
9. Compaction pin: The pressure in the center, to grind fixture put some pressure.
10. Prevent turn pin: Insert in jig anti turn groove, prevent grind chassis rotation.
